Product Details:
|
| Purpose: | Home Car Charging Station | Condition: | New |
|---|---|---|---|
| Interface Standard: | 4G, RFID, CAN | Output Power: | ＞100kW |
| Input Voltage: | 380V, 380Vac ±15% | Product Name: | EV Charger |
| Combination: | RFID, Wechat, Alipay | Connection: | 4G, RFID, CAN |
| Charging Port: | GB/T | Input Frequency: | 45~65Hz |
| Input Power Factor: | ≥0.99 | Module Constant Power Range: | 300-1000Vdc |
| Output Module Platform: | 30kW, 40kW | Protection Class: | IP54 |
Product Model | SNEV-1000/120-F-2-A1, SNEV-1000/160-F-2-A1, SNEV-1000/180-F-2-A1, SNEV-1000/240-F-2-A1 | Product Name | 120kw/160kw/180kw/240kwDC integrated machine |
Input Voltage | 380Vac ±15% | Protection level | IP54 |
Input Frequency | 45～65Hz | Altitude | ≤2000m, more than 2000m need to derate output |
Input Power Factor | ≥0.99 | Operating Humidity | 0%-95%, non-condensing |
Module constant power range | 300-1000Vdc | Operating Temperature | -30℃~+65℃, derating output above 50℃. |
Output Voltage Range | 200-1000Vdc, support minimum DC 50V output | Equipment Size | 750mm*615mm*1790mm |
Modular Platform | 30kW | Number of DC Outputs | dual |
